55 410 AIR CONDITIONER UNIT for Mitsubishi Fuso (2018, BG640G-0300001)

  • Chassis No BG640G-0300001
  • Vehicle Name ROSA JPN
  • Product Year 06/04/2018
  • Vehicle Model BG640
  • Model Year 2017
  • Classification Name WB-G STD AMT
  • Eng Model 4P101A4B
  • Eng No D14693
  • TM Model M038S6A285
  • TM No ZL82355
  • Axle RR Model R020BW1101
  • Axle RR No 384119
  • Em Mark TPG

There is several schemes for current parts group, choose the one you need.

Parts

Attention!

At the request of the manufacturer, we do’t show the full catalog numbers in the public catalog until the purchase is made.

If you have the OEM part number of the part you need, you should use search OEM page.

  Name and number Req Weight Period of application Price
87011 BRACKET,A/C COOLING UNIT,UPR
ME7357* 		4 — 10/01/2015 — 09/01/2018 quote request
87024 COVER,A/C DUCT BLIND
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥1,943
US$12.56€10.72
87037 HOSE,A/C EVAPORATOR DRAIN
12X1950
 MC1837* 		2 — 10/01/2015 — 09/01/2018 JP¥2,048
US$13.24€11.30
87037B HOSE,A/C EVAPORATOR DRAIN
ME7356* 		2 — 10/01/2015 — 09/01/2018 quote request
87037C HOSE,A/C EVAPORATOR DRAIN
ME7357* 		1 — 10/01/2015 — 09/01/2018 quote request
87037D HOSE,A/C EVAPORATOR DRAIN
ME7357* 		1 — 10/01/2015 — 09/01/2018 quote request
87086 VALVE,A/C EXPANSION
ME7354* 		1 0.25 kg 10/01/2015 — 09/01/2018 JP¥26,621
US$172.07€146.86
87087B PIPE,A/C EXPANSION VALVE INLET
ME7356* 		1 — 10/01/2015 — 09/01/2018 JP¥3,728
US$24.10€20.57
87106 CASE,A/C
ME7671* 		1 — 10/01/2015 — 09/01/2018 JP¥80,220
US$518.52€442.54
87162L DUCT,ROOF A/C,FR LH
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥8,610
US$55.65€47.50
87162R DUCT,ROOF A/C,FR RH
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥8,610
US$55.65€47.50
87163L DUCT,A/C EVAPORATOR,INR LH
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥11,550
US$74.66€63.72
87163R DUCT,A/C EVAPORATOR,INR RH
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥11,550
US$74.66€63.72
87164L DUCT,A/C EVAPORATOR,OTR LH
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥8,768
US$56.67€48.37
87164R DUCT,A/C EVAPORATOR,OTR RH
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥8,768
US$56.67€48.37
87165L DUCT,A/C EVAPORATOR OTR DUCT SIDE,LH
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥4,988
US$32.24€27.52
87165R DUCT,A/C EVAPORATOR OTR DUCT SIDE,RH
MC1813* 		1 — 10/01/2015 — 09/01/2018 JP¥4,988
US$32.24€27.52
87166B BRACKET,A/C EVAPORATOR UNIT
MC1813* 		2 — 10/01/2015 — 09/01/2018 JP¥3,885
US$25.11€21.43
87181C FILTER,A/C AIR
ME7356* 		1 — 10/01/2015 — 09/01/2018 JP¥5,250
US$33.93€28.96
87232B FAN & MOTOR,A/C EVAPORATOR
ME7359* 		2 3 kg 10/01/2015 — 09/01/2018 JP¥34,210
US$221.12€188.72
87232C FAN & MOTOR,A/C EVAPORATOR
ME7359* 		2 2.4 kg 10/01/2015 — 09/01/2018 JP¥31,351
US$202.64€172.95
87233B FAN,A/C EVAPORATOR
ME7357* 		2 — 10/01/2015 — 09/01/2018 quote request
87233C FAN,A/C EVAPORATOR
ME7357* 		2 — 10/01/2015 — 09/01/2018 JP¥3,203
US$20.70€17.67
87234B MOTOR,A/C EVAPORATOR FAN
ME7359* 		2 1.92 kg 10/01/2015 — 09/01/2018 JP¥29,481
US$190.56€162.64
87234C MOTOR,A/C EVAPORATOR FAN
ME7359* 		2 2 kg 10/01/2015 — 09/01/2018 JP¥29,481
US$190.56€162.64
87235A ARMATURE ASSY,A/C EVAPORATOR FAN MOTOR
ME7357* 		4 0.68 kg 10/01/2015 — 09/01/2018 JP¥12,046
US$77.86€66.45
87236B CASE,A/C EVAPORATOR FAN
ME7359* 		2 — 10/01/2015 — 09/01/2018 JP¥12,600
US$81.44€69.51
87236C CASE,A/C EVAPORATOR FAN
ME7359* 		2 — 10/01/2015 — 09/01/2018 quote request
87236D CASE,A/C EVAPORATOR FAN
ME7359* 		2 — 10/01/2015 — 09/01/2018 quote request
87236E CASE,A/C EVAPORATOR FAN
ME7359* 		2 — 10/01/2015 — 09/01/2018 quote request
87237 COLLAR,A/C INR
ME7351* 		12 — 10/01/2015 — 09/01/2018 quote request
87238A PAN ASSY,A/C EVAPORATOR DRAIN
ME7357* 		1 — 10/01/2015 — 09/01/2018 quote request
87239B BRACKET,A/C EVAPORATOR FAN
ME7670* 		8 — 10/01/2015 — 09/01/2018 quote request
87239D BRACKET,A/C EVAPORATOR FAN
ME7670* 		1 — 10/01/2015 — 09/01/2018 quote request
87239E BRACKET,A/C EVAPORATOR FAN
ME7670* 		1 — 10/01/2015 — 09/01/2018 quote request
87239F BRACKET,A/C EVAPORATOR FAN
ME7670* 		1 — 10/01/2015 — 09/01/2018 quote request
87239G BRACKET,A/C EVAPORATOR FAN
ME7670* 		1 — 10/01/2015 — 09/01/2018 quote request
87239H BRACKET,A/C EVAPORATOR FAN
ME7670* 		1 — 10/01/2015 — 09/01/2018 quote request
87241AB HOLDER ASSY,A/C EVAPORATOR FAN MOTOR BRUSH
ME7357* 		2 0.07 kg 10/01/2015 — 09/01/2018 JP¥6,656
US$43.02€36.72
87241AC HOLDER ASSY,A/C EVAPORATOR FAN MOTOR BRUSH
ME7357* 		2 0.07 kg 10/01/2015 — 09/01/2018 JP¥2,894
US$18.71€15.97
87296 VALVE,A/C EVAPORATOR SOLENOID
ME7356* 		1 0.38 kg 10/01/2015 — 09/01/2018 JP¥17,600
US$113.76€97.09
87313B INSULATOR,A/C EVAPORATOR
ME7356* 		1 — 10/01/2015 — 09/01/2018 part number changed
replacement code: O (?)
INSULATOR,A/C EVAPORATOR
ME7670* 		— JP¥1,029
US$6.65€5.68
87314 BRACKET,A/C EVAPORATOR DUCT
ME7670* 		4 — 10/01/2015 — 09/01/2018 JP¥294
US$1.90€1.62
87315 INSULATOR,A/C EVAPORATOR DUCT
ME7355* 		4 — 10/01/2015 — 09/01/2018 quote request
87401B BRACKET,A/C COOLING UNIT,LWR
ME7359* 		2 — 10/01/2015 — 09/01/2018 JP¥14,595
US$94.34€80.52
87401C BRACKET,A/C COOLING UNIT,LWR
ME7359* 		2 — 10/01/2015 — 09/01/2018 quote request
87415 HARNESS,A/C CONTROL
ME7671* 		1 — 10/01/2015 — 09/01/2018 quote request
87415B HARNESS,A/C CONTROL
MK4570* 		1 — 10/01/2015 — 09/01/2018 JP¥2,625
US$16.97€14.48
87433 EVAPORATOR,RR A/C UNIT
ME7357* 		1 9.62 kg 10/01/2015 — 09/01/2018 JP¥148,050
US$956.95€816.74
87455 JOINT,RR A/C DRAIN HOSE
ME7355* 		2 — 10/01/2015 — 09/01/2018 JP¥179
US$1.16€0.99
87456 PLATE,RR A/C
ME7670* 		1 — 10/01/2015 — 09/01/2018 quote request
87496B CLAMP,A/C
D=25
 MS4764* 		1 0.04 kg 10/01/2015 — 09/01/2018 JP¥305
US$1.97€1.68
87498B BOLT,A/C
ME7357* 		8 — 10/01/2015 — 09/01/2018 JP¥315
US$2.04€1.74
87498C BOLT,A/C
7T
 8X20
 MF1402* 		8 0.01 kg 10/01/2015 — 09/01/2018 JP¥263
US$1.70€1.45
87498D BOLT,A/C
4T
 6X12
 MF1400* 		4 — 10/01/2015 — 09/01/2018 part number changed
replacement code: Y (?)
BOLT,A/C
4T
 6X12
 MS1000* 		— JP¥189
US$1.22€1.04
87498E BOLT,A/C
WASHER ASSEMBLED 6X16
 ME7356* 		6 — 10/01/2015 — 09/01/2018 quote request
87498F BOLT,A/C
WASHER ASSENBLED 6X20
 MC7350* 		3 — 10/01/2015 — 09/01/2018 part number changed
replacement code: Y (?)
BOLT,A/C
WASHER ASSENBLED 6X20
 MF2436* 		0.006 kg JP¥252
US$1.63€1.39
87499 BAND,A/C
L=150
 MC3283* 		3 0.008 kg 10/01/2015 — 09/01/2018 JP¥305
US$1.97€1.68
87499 BAND,A/C
L=219.5
 MB0840* 		5 0.2 kg 10/01/2015 — 09/01/2018 part number changed
replacement code: Y (?)
BAND,A/C
L=219.5
 MB2493* 		0.001 kg JP¥273
US$1.76€1.51
87581B SENSOR UNIT,A/C TEMPERATURE
MC9306* 		2 0.02 kg 10/01/2015 — 09/01/2018 JP¥2,363
US$15.27€13.04
87672B GROMMET,A/C
D=18 T=13.7
 MH0223* 		1 0.1 kg 10/01/2015 — 09/01/2018 JP¥515
US$3.33€2.84
87672C GROMMET,A/C
ME7351* 		12 — 10/01/2015 — 09/01/2018 JP¥588
US$3.80€3.24
87673B CLIP,A/C
MB1325* 		4 0.004 kg 10/01/2015 — 09/01/2018 JP¥326
US$2.11€1.80
87673C CLIP,A/C
GRAY
 MB4460* 		6 0.002 kg 10/01/2015 — 09/01/2018 JP¥273
US$1.76€1.51
87673E CLIP,A/C
ME7351* 		1 — 10/01/2015 — 09/01/2018 quote request
87673F CLIP,A/C
D=15.5
 MS6601* 		2 0.008 kg 10/01/2015 — 09/01/2018 JP¥347
US$2.24€1.91
87673G CLIP,A/C
D=20,6.5
 MT1884* 		1 0.01 kg 10/01/2015 — 09/01/2018 JP¥368
US$2.38€2.03
87673H CLIP,A/C
MB6305* 		5 — 10/01/2015 — 09/01/2018 quote request
87689B WASHER,A/C
ME7357* 		4 — 10/01/2015 — 09/01/2018 JP¥5,723
US$36.99€31.57
87689D WASHER,A/C
ME7351* 		4 — 10/01/2015 — 09/01/2018 quote request
87689E WASHER,A/C
ME7351* 		12 — 10/01/2015 — 09/01/2018 JP¥2,468
US$15.95€13.62
87689G WASHER,A/C
PLAIN 6
 MF4501* 		1 0.003 kg 10/01/2015 — 09/01/2018 JP¥168
US$1.09€0.93
87692B SCREW,A/C
TAPPING 6X14
 MF4530* 		7 0.008 kg 10/01/2015 — 09/01/2018 JP¥263
US$1.70€1.45
87692C SCREW,A/C
COLORED
 MACHINE FLANGE 4T 6X16
 MS2003* 		1 0.003 kg 10/01/2015 — 09/01/2018 JP¥210
US$1.36€1.16
87692D SCREW,A/C
WASHER ASSEMBLED 4T 5X16
 MF2436* 		12 0.005 kg 10/01/2015 — 09/01/2018 part number changed
replacement code: Y (?)
SCREW,A/C
WASHER ASSEMBLED 4T 5X16
 MB1168* 		— JP¥189
US$1.22€1.04
87692E SCREW,A/C
5X12
 MF4530* 		4 0.01 kg 10/01/2015 — 09/01/2018 JP¥252
US$1.63€1.39
87692F SCREW,A/C
ME7357* 		24 — 10/01/2015 — 09/01/2018 JP¥441
US$2.85€2.43
87693B PLUG,A/C
ME7358* 		4 — 10/01/2015 — 09/01/2018 JP¥1,040
US$6.72€5.74
87695 O-RING,A/C
MR1169* 		1 0.001 kg 10/01/2015 — 09/01/2018 quote request
87696C NUT,A/C
FLANGE
 ME7351* 		4 — 10/01/2015 — 09/01/2018 JP¥179
US$1.16€0.99
